Greentek is a manufacturer of reusable gold coated EEG cup Electrodes. We have been supplying EEG caps and EEG accessories like EEG cup electrodes throughout the world with superior quality and best services.

Greentek reusable EEG Gold Cup Electrode is made of 99.99% pure copper with gold coating. Lead length is standard 0.75m, 1.0m, 1.5m, 2m and 2.5m. Terminated in 1.5mm female DIN42802 connector, perfect for neuro-feedback and clinical EEG applications.

The 2.0 mm holes in the center of the electrodes permits site preparation and delivery of the conductive electrolyte. The lead wire is made of multistrand Silver plated copper foil wire+bulletproof fibre + medical TPU outsider. Thus this kind of electrodes have good quality—flexibility, fatigue resistance, stretching resistance, and provide a stable, accurate and reliable EEG recording.

Greentek is a manufacturer of reusable Gold coated EEG Cup Electrodes. We have been supplying EEG Caps and EEG accessories like EEG cup electrodes throughout the World with superior quality and best services.

Greentek reusable Gold coated EEG cup electrode is made of 99.99% pure copper with gold coating. Lead length is standard 0.75m, 1.0m, 1.5m, 2m and 2.5m. Terminated in 1.5mm female DIN42802 connector, perfect for neuro-feedback and clinical EEG applications.

The 2-mm holes in the center of the electrodes permits site preparation and delivery of the conductive electrolyte. The lead wire is made of multistrand Silver plated copper foil wire+bulletproof fibre + medical TPU outsider. Thus this kind of electrodes have good quality—flexibility,fatigue resistance, stretching resistance. Provide a stable, accurate and reliable EEG recording

Specifications

Specifications

Product Name Greentek EEG Gold Cup Electrodes
Application EEG, EMG, EOG, PSG, ERP …
Electrode Material Gold plated copper
Electrode Diameter 10.0 mm, with 2.0 mm hole for application of electrode cream or gel
Insulation materials Medical grade TPU
Lead wire Core Kevlar and silver plated copper
Cable Length 0.75m & 1.5m & 2.0m & 2.5m & OEM
Connector 1.5mm female DIN42802 connector (touchproof )
Cable Color 12 Colors
Packaging 12 pcs / PE Bag
Certificate CFDA, ISO 13485, CE
Place of Origin China
Place of Origin * Better performance, quality material make the good product
* Durable and stable, the thickness of the coating is 3µ
* Low offset voltage, Low noise, the impedance is below 5k Ohm
* Reusable and non-toxic,can be reused after sterilized

Product Name Greentek EEG Gold Cup Electrodes
Application EEG, EMG, EOG, PSG, ERP …
Electrode Material Gold plated Copper
Electrode Diameter 10.0 mm, with 2 mm hole for application of electrode cream or gel
Insulation materials Medical Grade TPU
Lead wire Core Kevlar and Silver plated Copper
Cable Length 0.75m & 1.5m & 2.0m & 2.5m & OEM
Connector 1.5mm female DIN42802 connector (touchproof )
Cable Color 12 Colors
Packaging 12 pcs / PE Bag
Certificate CFDA, ISO 13485, CE
Place of Origin China
Features * Better Performance, quality material make the good product
* Durable and stable, the thickness of the coating is 3µ
* Low offset voltage, Low noise, the impedance is below 5 k Ohm
* Reusable and non-toxic,can be reused after sterilized
